SBJ Series Waste Paper Bale Breaker

Introduction

Dry method to remove light and heavy impurity efficiently

To improve labor’s work environment

To reduce the load and energy consumption of subsequent screening

To reduce the wear of subsequent pulp equipment.

Advantages

Energy saving （ for example, light impurity cleaner, heat dispersion）

To enhance the efficiency of hydrapulper.

To enhance the space saving of waste paper and its impurity.

To enhance the cleanliness of paper.

Operating Principle

1.Break bales function:

Compact packaging waste paper bales is conveyed from chain conveyor to feed bins, then to Dry screening System for Bale Breaking. Under the reliable mechanical structure of professional design, the waste paper bales can be broken into sheets in short time.

2.Screen and remove impurity function:

The small light and heavy impurity which is mixed up in waste paper would be screened from professional design screener.

3.selection and classification function:

Large impurity, heavy impurity, inferior waste paper, and high-grade paper which are spread out in sheets are distributed on the chosen chain plate. Exposed large light and heavy impurity, some waste paper adverse to pulp making, and some high-grade paper are sorted out to use more effective.
